Property Name |
Usage |
Details |
Domain |
The domain name of the
SMTP server. |
Host Name |
The hostname or IP address
of the SMTP server. |
IMAP Port No. |
Port number of the IMAP
protocol. It is an advanced protocol compared to POP3
protocol for mail server connection. The default value
of IMAP port is 143. You can edit the port number if the
server is configured using different port number. If IMAP
port number is not known, leave the field with the default
value while configuring the SMTP application in Automation
Studio. |
POP3 Port No. |
Port number of the POP3
protocol. The default value of POP3 port is 110. You can
edit the port number if the server is configured using
different port number. |
Single Attachment Size
Limit (MB) |
The maximum file size
of the attachment allowed to be sent in an e-mail using
SMTP, specified in MB. By default, the single attachment
size is 5 MB. |
SMTP Port No. |
The port used to connect
to the SMTP server. The default value of SMTP port is
25. You can edit the port number if the server is configured
using different port number. |
SSLEnabled |
Signifies if SSL is enabled.
By default, it is set to False. |
Total Attachment Size
Limit (MB) |
Total file size of the
attachment allowed to be sent in an e-mail using SMTP,
specified in MB. By default, the total attachment size
is 10 MB. |
Validate Channel |
If user id used to connect
to the server is same as the from email address in Send E-Mail activity,
then set this value to true, else to false. By default,
it is set to False. |
Display |
Application Description |
A small description of
the FTP or the SFTP application added. |
Display Name |
The desired name of the
application entered b the user. This is a mandatory field. |
General |
Application Name |
Name of the application
entered at the time of adding the application. It auto
populates as per the name of the application entered while
configuring the application. |
Application Type |
Type of the application
selected at the time of adding the application. It auto
populates as per the application type selected while configuring
the application. |
Misc |
Is Application Tracked |
Is applicable only for
AssistEdge Engage.
Signifies if the application
is tracked for time spent by Engage during the process
execution. It used for activity tracking report and tracking
time spent on each application in the execution dashboard
reports. By default it is set to true. |
Is multiInstance allowed |
It has been decommissioned
now.
It was applicable only for
AssistEdge SE (until version 8.6) which is AssistEdge
Engage now.
Signifies if multiple instances
of SE (now Engage) processes can be initiated on a single
user machine. |
Reset |
Is Reset Required |
Signifies if the application
reset needs to be done after each automation is executed.
If it is not selected, the application does not reset. |
Is Sequential Reset |
Signifies if the application
reset needs to be done one after other in no particular
order. If it is selected, it is mandatory to have a Reset
Process for that particular application created and
used inside the application. |
Sequential
Launch/SignIn |
Is Sequential SignIn |
Signifies if signing in
to the application is required by the automation process
in a sequence in which the application is used in the
process. If it is selected, it is mandatory to have a
SignIn
Process for that particular application created and
used inside the application. |
SignIn |
SignIn |
Signifies sign in to the
SMTP server is required. Be default, it is set to
True and can not
be edited because when the SMTP server is used in the
Automation Studio, it logind to the SMTP server for connection,
before proceeding further. |
The SMTP server is configured.
