It allows you to configure
database application to Automation Studio.
Property Name |
Usage |
Details |
DB Type |
The type of database application configured. Supported
types are:
· SQL
· Oracle
· MySQL
· Excel |
Authentication Type(SQL) |
The type of authentication configured in the SQL
database. Appears when DB
Type is set to SQL
or Oracle. Available
options are:
· SQL
- system uses the SQL database pass
· Windows
- system automatically connects to the database application
using system password. |
DB Server |
The server name where database is hosted for database
storage and retrieval.
This information is fetched from the SQL Server Management
Studio if DB Type
is SQL.
This information is available in Oracle SQL Developer
if DB Type is
Oracle. |
DB Port |
The port number to connect to the database server. |
DB Name |
The name of the database created. |
SID(Oracle) |
The unique name of the Oracle database instance.
Appears when DB Type
is set to Oracle.
This information is available in Oracle SQL Developer. |
Excel Directory Path (Example - D:\folder) |
The path of the excel application saved on the system.
For example, D:\folder. |
Display |
Application Description |
A small description of the web application added. |
Display Name |
The desired name of the application entered
by the user. This is a mandatory field. |
General |
Application Name |
Name of the application entered at the time of adding
the application. It auto populates as per the name of
the application entered while configuring the application. |
Application Type |
Type of the application selected at the time of
adding the application. It auto populates as per the application
type selected while configuring the application. |
Misc |
Is Application Tracked |
Is applicable only for AssistEdge Engage.
Signifies if the application is tracked for time spent
by Engage during the process execution. It used for activity
tracking report and tracking time spent on each application
in the execution dashboard reports. By default the check
box is selected and can be edited. |
Is multiInstance allowed |
It has been decommissioned now.
It was applicable only for AssistEdge SE (until version
8.6) which is AssistEdge Engage now.
Signifies if multiple instances of SE (now Engage) processes
can be initiated on a single user machine. |
Reset |
Is Reset Required |
Signifies if the application reset needs to be done
after each automation is executed. If it is not selected,
the application does not reset. |
Is Sequential Reset |
Signifies if the application
reset needs to be done one after other in no particular
order. If it is selected, it is mandatory to have a Reset
Process for that particular application created and
used inside the application. |
Sequential
Launch/SignIn |
Is Sequential SignIn |
Signifies if signing in to the application is required
by the automation process in a sequence in which the application
is used in the process. If it is selected, it is mandatory
to have a SignIn
Process for that particular application created and
used inside the application. |
SignIn |
SignIn |
Signifies if sign in to the database application
is required. Be default, it is set to True and can not be
edited. |
The database application is configured.
